Low Profile Deckover Trailer
The pierced beam frame design lowers the deck height for improved stability and easier loading, making this trailer ideal for heavy equipment and oversized loads.
The torque tube adds rigidity and support over the axles, reducing flex and enhancing structural integrity for heavy or unevenly distributed loads.
The rugged slipper spring suspension system absorbs road shock, enhancing stability and protecting your cargo during transport.
The self-cleaning dovetail and heavy-duty ramps simplify loading and unloading, while the full-width deck maximizes usable space for wide or oversized machinery.
—
Standard Colors
Optional Colors
Colors may vary slightly.
Contact your local dealer for color samples.
The H&H Low Profile Deckover Trailer is designed to handle the needs of medium-duty haulers with strength and reliability. With its low-profile, pierced I-Beam frame and enhanced structural reinforcements, this gooseneck equipment trailer delivers exceptional strength and an easier loading experience. Whether you're transporting construction equipment or farm machinery, this deckover trailer combines superior design with real-world performance to keep your operation moving.
Choose from a variety of deck lengths, axle configurations, and GVWR ranging from 15.4K to 17.6K to tailor the Low Profile Deckover Trailer to your specific needs. Each model is built with the same commitment to quality, making it the ideal flatbed trailer for professional and personal hauling jobs alike.
Every Low Profile Deckover Trailer comes equipped with premium features, including a pierced I-Beam frame, torque tube system, and a heavy-duty slipper spring suspension system. Dovetail, ramps, rub rails, stake pockets, and chain spools are standard, giving you ample tie-down points and a versatile, easy-loading platform. LED lighting, powder-coated finish, and robust construction complete the package, ensuring durability and long-term value for your equipment trailer investment.
Customize your deck over trailer to meet your unique requirements. Available options include bumper pull configurations, gooseneck height increases, upgraded flooring materials, winch plates, multiple tie-down configurations, and hydraulic jacks. Whatever your project demands, H&H provides the solutions to outfit your trailer your way.
Model # | H20L-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 4210 lbs |
Model # | H20L-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 4320 lbs |
Model # | H20L-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 4300 lbs |
Model # | H20L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 4820 lbs |
Model # | H25L-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H25L-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5260 lbs |
Model # | H20+5SDBCL-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5100 lbs |
Model # | H20+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5525 lbs |
Model # | H25L-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H25L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 5145 lbs |
Model # | H20+5SDBCL-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 5330 lbs |
Model # | H20+5SDBCL-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 5950 lbs |
Model # | H23+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 6270 lbs |
Model # | H23+5SDBCL-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 6350 lbs |
Model # | H30L-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5110 lbs |
Model # | H30L-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5820 lbs |
Model # | H25+5SDBCL-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 5770 lbs |
Model # | H25+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 6190 lbs |
Model # | H30L-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H30L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H25+5SDBCL-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 6365 lbs |
Model # | H25+5SDBCL-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 6155 lbs |
Model # | H32L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 6445 lbs |
Model # | H35L-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H35L-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H30+5SDBCL-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H30+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight | 6320 lbs |
Model # | H35L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H30+5SDBCL-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight | 6665 lbs |
Model # | H30+5SDBCL-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H40L-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H40L-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H35+5SDBCL-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H35+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H40L-B-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H40L-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H35+5SDBCL-GN-176 |
GVWR (lbs) | 17600 lbs |
GAWR (lbs/axle) | 8000 lbs/axle |
Curb Weight |
Model # | H40+5SDBCL-B-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Model # | H40+5SDBCL-GN-150 |
GVWR (lbs) | 15000 lbs |
GAWR (lbs/axle) | 7000 lbs/axle |
Curb Weight |
Features and Specifications subject to change without notice. Please contact your local dealer for confirmation.
